12960 Series
Brass Ball Valve Female x Female Threaded NPT with Yellow Handle
 |
|---|
 |
 |
 |
 |
 |
 |
 |
 |
Features:
Brass Body
Sizes: 1/4"-1"
Connection: Female x Female NPT
Certifications: CSA | FM
Standard: ANSI B1.20.1
Yellow Handle
Pressure:
920 PSI (1/4"-3/8")
580 PSI (1/2" - 1")
Temperature: -4° F to 140° F for Gas Application;
-4° F to 266° for All Other Applications
Application: Hot and Cold Water, Compressed Air, Oils, All Kinds of Gases, Non-aggressive Fluids
Item | Size | Connection Type | Inner Case Qty | Master Case Qty | MC Weight lbs |
12960-002 | 1/4" | Female x Female NPT | 25 | 200 | 29.08 |
12960-003 | 3/8" | Female x Female NPT | 25 | 125 | 35.125 |
12960-005 | 1/2" | Female x Female NPT | 20 | 80 | 31.217 |
12960-007 | 3/4" | Female x Female NPT | 6 | 36 | 28.028 |
12910-010 | 1" | Female x Female NPT | 12 | 48 | 28.0224 |
